Frame Filter Press
- Introduction
- Frame filter press is a comprehensive automatic filtering equipment, with high automation, stable performance, safety and reliability. It has been widely used in the field of solid-liquid separation.
- Capacity
- 5-250㎡/time
Description
- Frame filter press is a piece of sludge dewatering equipment that separates liquids and solids using pressure filtration in the sludge management. When working, slurry will be pumped into press chambers and dewatered with pressure. Each unit need to be designed based on the types of slurry as well as the volumes. Our filter presses are supplied for a wide application in municipal & industrial wastewater treatment. Feed mud concentration always be 30%-40%, then mud will become mud cake and the humidity is around 20% after processed. Frame filter press is a kind of Plate and Frame Filter Press, some now call it as “Chamber Filter Press”. Typically, no flocculant are needed to help dewatering on a plate filter press.
Advantages
-
1
Filter presses are high strength, light weight, corrosion resistance, acid and alkali, non-toxic and tasteless. -
2
The frame rack is high strength, stable structure, long service life, small footprint. -
3
Automatic pull plate, liquid automatic access, operation panel is simple and safe, high degree of automation. -
4
Hydraulic system is used as the power unit, the maximum pressure is 25MPa. -
5
Filter cake dryness, filtration cycle time, materials of components, number of chambers, filter plate size, filtration capacity is all stringently.
Structure
Slurry is pumped into the filter press by high-pressure slurry pumps, the mixture flows through the filter medium (filter cloth), the solids stay on the filter cloths, forming filter cake; the filtrate exits the filter plates through the corner ports into the manifold, If it is not wanted the filtrate can be drained away for safe disposal.
Filter press is a pressure filtration method, which has the characteristics of fixed volume and batch operation, when the feed pumps generate pressure, solids build up in chambers until they are completely chock-full of. Once the chambers are full of solids, a fill cycle is over and the de-watered filter cakes will release, repeat the cycle, filter press will work cyclically.
Technical Parameters
Model | Filter Area㎡ | Filter Chamber Volume L | Filter Plate Size mm | Filter Plate Thickness mm | Filter Chamber Quantity pcs | Filter Cake Thickness mm | Size LXWXH | Weight Kg |
A B XMY5/520-UK | 5 | 70 | 520X520 | 60 | 13 | 30 | 1980X800X900 | 980 |
A B XMY8/520-UK | 8 | 112 | 520X520 | 60 | 19 | 30 | 2230X800X900 | 1060 |
A B XMY10/520-UK | 10 | 140 | 520X520 | 60 | 28 | 30 | 2480X800X900 | 1110 |
A B XMY5/650-UK | 5 | 70 | 650X650 | 60 | 7 | 30 | 2270X870X1150 | 980 |
A B XMY8/650-UK | 8 | 112 | 650X650 | 60 | 12 | 30 | 2520X870X1150 | 1060 |
A B XMY10/650-UK | 10 | 140 | 650X650 | 60 | 15 | 30 | 2670X870X1150 | 1110 |
A B XMY15/650-UK | 15 | 220 | 650X650 | 60 | 22 | 30 | 2950X870X1150 | 1200 |
A B XMY20/650-UK | 20 | 280 | 650X650 | 60 | 30 | 30 | 3470X870X1150 | 1360 |
A B XMY20/800-UK | 20 | 320 | 800X800 | 60 | 20 | 30 | 3560X1085X1265 | 2240 |
A B XMY25/800-UK | 25 | 400 | 800X800 | 60 | 25 | 30 | 3800X1085X1265 | 2580 |
A B XMY30/800-UK | 30 | 480 | 800X800 | 60 | 30 | 30 | 4160X1085X1265 | 2700 |
A B XMY40/800-UK | 40 | 640 | 800X800 | 60 | 40 | 30 | 4760X1085X1265 | 2922 |
A B XMY50/800-UK | 50 | 800 | 800X800 | 60 | 50 | 30 | 5360X1085X1265 | 3250 |
A B XMY60/800-UK | 60 | 960 | 800X800 | 60 | 60 | 30 | 5960X1085X1265 | 3590 |
A B XMY70/800-UK | 70 | 1120 | 800X800 | 60 | 70 | 30 | 6560X1085X1265 | 4080 |
A B XMY80/800-UK | 80 | 1280 | 800X800 | 60 | 80 | 30 | 7160X1085X1265 | 4450 |
A B XMY40/920-UK | 40 | 640 | 920X920 | 60 | 32 | 30 | 4290X1210X1415 | 3150 |
A B XMY50/920-UK | 50 | 800 | 920X920 | 60 | 40 | 30 | 4770X1210X1415 | 3680 |
A B XMY60/920-UK | 60 | 960 | 920X920 | 60 | 48 | 30 | 5250X1210X1415 | 3890 |
A B XMY70/920-UK | 70 | 1120 | 920X920 | 60 | 56 | 30 | 5730X1210X1415 | 4050 |
A B XMY80/920-UK | 80 | 1280 | 920X920 | 60 | 64 | 30 | 6210X1210X1415 | 4360 |
A B XMY90/920-UK | 90 | 1440 | 920X920 | 60 | 72 | 30 | 6690X1210X1415 | 4670 |
A B XMY100/920-UK | 100 | 1600 | 920X920 | 60 | 80 | 30 | 7170X1210X1415 | 4980 |
A B XMY50/1000-UK | 50 | 750 | 1000X1000 | 60 | 30 | 30 | 4756X1456X1400 | 4780 |
A B XMY60/1000-UK | 60 | 900 | 1000X1000 | 60 | 36 | 30 | 5122X1456X1400 | 5060 |
A B XMY70/1000-UK | 70 | 1050 | 1000X1000 | 60 | 42 | 30 | 5488X1456X1400 | 5340 |
A B XMY80/1000-UK | 80 | 1200 | 1000X1000 | 60 | 48 | 30 | 5854X1456X1400 | 5620 |
A B XMY90/1000-UK | 90 | 1350 | 1000X1000 | 60 | 54 | 30 | 6220X1456X1400 | 5900 |
A B XMY100/1000-UK | 100 | 1500 | 1000X1000 | 60 | 60 | 30 | 6586X1456X1400 | 6460 |
A B XMY120/1000-UK | 120 | 1800 | 1000X1000 | 60 | 72 | 30 | 7318X1456X1400 | 6740 |
A B XMY100/1250-UK | 100 | 1500 | 1250X1250 | 60 | 38 | 30 | 4900X1750X1600 | 8590 |
A B XMY120/1250-UK | 120 | 1800 | 1250X1250 | 60 | 45 | 30 | 5000X1750X1600 | 9540 |
A B XMY150/1250-UK | 150 | 2200 | 1250X1250 | 60 | 56 | 30 | 5300X1750X1600 | 10120 |
A B XMY(Z)200/1250UK | 200 | 3000 | 1250X1250 | 60 | 75 | 30 | 6900X1750X1600 | 11530 |
A B XMY(Z)250/1250UK | 250 | 3750 | 1250X1250 | 60 | 94 | 30 | 7580X1750X1600 | 14100 |
