Agitation Tank
- Capacity
- 0.0785～45m³
- Improvement
- The cylinder body can be lined with wear resistant and anti-corrosion rubber liner, it effectively extend the service life of the equipment. Its application field can be extended to the mixing of abrasive and corrosive slurry.
Description
- Introduction
- Agitation Tank is mainly applied in slurry stirring before the flotation, chemical and construction industry, cyanide chemical plant, sewage treatment plant, and coal plant etc.
Advantages
-
1
The cylinder is lined with wear-resistant rubber with strong resistance to wear and corrosion; -
2
Strong agitation capability; -
3
Stable operation, convenient maintenance; -
4
Energy-saving.
Structure
Agitation tank rotaries by the V-belt drives the impeller and mash mix even engough, increase the medicine effect time, strength the medicine effect quantity, necessity set. Agitation tank fits concentrating, and every chemical industry mixing.
Technical Parameters
| Model | Effective Volume (m3) | Rotating Speed of Impeller (r/min) | Diameter of Impeller (mm) | Motor Model | Motor Power (kW) | weight （kg) |
| BJ-500X500 | 0.0785 | 493 | 160 | Y80L-4 | 0.55 | 120 |
| BJ-750X750 | 0.25 | 530 | 240 | Y100L-6 | 1.5 | 240 |
| BJ-1000X1000 | 0.58 | 530 | 310 | Y100L-6 | 1.5 | 680 |
| BJ-1500X1500 | 2.2 | 320 | 400 | Y132S-6 | 3 | 790 |
| BJ-1600X1800 | 2.6 | 331 | 400 | Y132M2-6 | 5.5 | 990 |
| BJ-2000X2000 | 4.4 | 230 | 550 | Y132M2-6 | 5.5 | 1800 |
| BJ-2000X2500 | 5.9 | 230 | 630 | Y160M-6 | 7.5 | 2106 |
| BJ-2500X2500 | 11.2 | 230 | 630 | Y160M-6 | 7.5 | 2766 |
| BJ-3000X3000 | 19.1 | 210 | 700 | Y225S-8 | 18.5 | 4613 |
| BJ-3500X3500 | 24 | 230 | 850 | Y225M-8 | 22 | 5980 |
| BJ-4000 X4000 | 45 | 153 | 1000 | Y250M-8 | 30 | 8910 |
