Description
- Introduction
- The mining trommel screen is to filter out the big stones in the original ore and wash away the mud in the original ore. We offer a variety of models, including mini trommel screen that can be operated by one person for small-scale mines and heavy-duty washing plant for big-scale mines. We have passed ISO and CE international certification, safety is guaranteed.
Advantages
-
1
Feeding system with grizzly hopper feeder, water spray pipes inside the hopper for spray waters to the soils; -
2
Heavy duty clay scrubber with inside high pressure water spray pipes for breaking off hard clay; -
3
Double gold recovery systems to ensure highest recovery rate of gold; -
4
Easy for installation, operation and maintaining.
Working
The drum screen is often used for the classification of powdery materials, the screening effect is good, the sieve holes are not easy to block with stable operation, low noise, great safety, and high productivity. And the structure is simple, the maintenance is convenient, providing a greater return on your investment. The special screen is used for higher screening efficiency and longer service life.
Technical Parameters
| SPECIFICATION OF MINING MACHINERY TROMMEL SCREEN WASH PLANT | |||||
| Model | VICM50 | VICM100 | VICM150 | VICM200 | VICM400 |
| Size | 7*2*3m | 8.5*2.5*3.5 | 9.8*3*4m | 12*3.2*4.5 | 15*3.5*5m |
| Capacity | 50-100 tph | 100-150tpp | 150-250 tph | 260-400tph | 400-450 tph |
| Power | 24kw | 55kw | 75kw | 120kw | 200kw |
| Feeder Hopper | 2*2.2m | 3*2.7 | 3.8*3m | 4.5*3.5m | 6*4m |
| Sluice box | 1*2m (2pcs) | 1*4m (2pcs) | 1*6m (3pcs) | 1*6m (5pcs) | 1*6m (7pcs) |
| Water power | 7.5kw | 25kw | 45kw | 85kw | 150kw |
| Clay Scrubber | 1*2m | 1.1*2.2m | 1.3*2.5m | 1.5*2.5m | 2*2.5m |
| Trommel Screen | 1.2*3m | 1.5*3.2m | 2*4m | 2*5.5m | 2*7m |
| Recovery Rate | 98% | 98% | 98% | 98% | 98% |
