Sand Washing and Dewatering Machine
- Capacity
- 50-200t/h
- Improvement
- The sand washing and dewatering machine integrate water washing and fine sand dewatering and recycling as a whole, so it is also called sand washing and recycling conjoined machine, fine sand recycling and dewatering integrated machine, mud and sand washing and separating equipment.
Description
- The sand washing and recycling machine is mainly divided into sand washing parts and fine sand recycling parts; the sand washing parts have the same functions as general wheel sand washing machines, and are used for water washing, dehydration, and mud removal; and the recycling parts can be combined according to customer needs If you need fine sand recovery, you can connect to a general fine sand recovery system. If you need fine sand dewatering, you can connect a dewatering type fine sand recovery machine. If you need different sand production effects, you can also configure a multi-layer dewatering screen.
Advantages
-
1
The dehydrated fine sand recovery machine has two functions of dehydration and recovery. One machine is multi-purpose and easy to operate, saving investment cost and floor area. -
2
The sand washing is cleaner, and the secondary sand washing and dewatering function is added for the finished sand of the sand washing machine, which is a higher feature of the dehydrated fine sand recovery machine. -
3
Improve the quality and output of the finished sand, and fully solve the problems of the sand washing machine (such as: large water content of the finished product, large amount of mud, more dust, difficult to clean impurities, etc.).
Working
The sand washing and recycling machine is composed of a pressure separator, a dewatering screen, an impeller separator, a reducer, a vacuum, a pressure pump, a cleaning box, a return water tank, a motor, a vibration motor, and other components.The inner self-cleaning performance, no plugging, high screening efficiency and long service life of the polyurethane elastic screen are due to the use of steel wire rope as the skeleton material, plus the polyurethane itself has a very high elastic modulus, high strength absorption impact, high wear resistance, so it has a very high tensile strength, and its bearing capacity is more than 2.5 times that of the rubber screen.
Technical Parameters
Model | Sand output (m3/h) | Fine sand treatment (m3/h) | Water treatment(m3/h) | High pressure separator specifications | Impeller separator model | Impeller separator moter | Impeller separator reducer | Dewatering Screen Model | Dewatering Screen Motor | Vacuum high pressure pump motor | Dimensions(mm) |
VIC26-30 | 20-50 | 43468 | 50-80 | 300 | 2600 | 8-5.5kw | ZQ350 | 1000x2000 | 1.1kw*2 | 4-7.5KW | 5400*2425*2680 |
VIC28-50 | 50-120 | 43532 | 60-130 | 500 | 2800 | 8-7.5kw | ZQ400 | 1250x2500 | 2.2kw*2 | 4-15KW | 6100*2486*2850 |
VIC30-70 | 120-180 | 43819 | 150-200 | 700 | 3000 | 8-11kw | ZQ500 | 1500x3000 | 3kw*2 | 4-15KW*2 | 6600*2686*3050 |
